ZGMG Auto Crawler Scissor Lift – Factory Price Aerial Work Platform Lift Equipment
126 sold in last 1 hour
Estimated Delivery: Thu, Mar 05 – Mon, Mar 09
... people are viewing this right now
Basic Info.
Model NO.
HC1216E-R
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Scissor Lift
Carrying Capacity
Weight Level
Moves
Self-propelled
Driven Type
AC
Running Mode
Moving
Feature
Explosion-Proof, Insulating
Certification
GS, CE, RoHS, ISO 9001, ANSI
Platform Capacity
320kg
Extension Platform
0.9m
Extension Capacity
113kg
Drive
Rear Crawler
Transport Package
High Quality Paper Boxes with Stretch Film
Specification
2.83m x 1.6m x 2.03m
Trademark
HERED
Origin
China
HS Code
84289090
Production Capacity
20000 Units / Year
Packaging & Delivery
Package Size
2.83cm * 1.60cm * 2.03cm
Package Gross Weight
3660.000kg
Product Description
Online consultation to get the lowest price
1. Optimized matching, high cycle times, better endurance.
2. Precise control greatly improves the smoothness of operating.
3. Large ground clearance, stronger passability
| MODEL | HC1216E-R |
| A-Max. Platform Height(In/out) | 11.8m/11.8m |
| Max. Working Height(In/out) | 13.8m/13.8m |
| B-Platform Length | 2.26m |
| C-Platform Width | 1.12m |
| Extension Size | 0.9m |
| D-Heights (Rails Up) | 2.63m |
| Height (Rails Down) | 2.03m |
| E-Overall Width with Outriggers | 2.83m |
| F-Overall Width | 1.6m |
| G- Ground Clearance | 150mm |
| PERFORMANCE | |
| Platform Capacity | 320kg |
| Extension Capacity | 113kg |
| Max. Occupancy(in/out) | 2/2 |
| Max.Wind Speed | 12.5m/s |
| Drive Speed (Stowed) | 4km/h |
| Turning Radius | Rotate in Place |
| Up/Down Time | 65/60s |
| Gradeability | 0.4 |
| Max. Slope | / |
| Leveling angle of the legs | 12°/5° |
| Drive | Rear Crawler |
| Crawler (mm) | 230mmX90mmX53 |
| POWER | |
| Batteries (V/Ah) | 8X6V/200Ah |
| Charger | 100-240VAC/13.5A |
| WEIGHT | |
| Weight | 3660kg |
