Basic Info.
Model NO.
HS1218ERT
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Scissor Lift
Carrying Capacity
Weight Level
Moves
Self-propelled
Driven Type
AC
Running Mode
Moving
Feature
Explosion-Proof, Insulating, Spillover Valve
Certification
GS, CE, RoHS, ISO 9001, ANSI
Control
Proportional Control
Drive
Four-Wheel
Tires (mm)
26X12-16
Charger
100-240VAC/13.5A
Transport Package
High Quality Paper Boxes with Stretch Film
Specification
3.750m x 1.750m x 2.88m
Trademark
HERED
Origin
China
HS Code
84289090
Production Capacity
20, 000 Sets /Year
Packaging & Delivery
Package Size
375.00cm * 175.00cm * 288.00cm
Package Gross Weight
5730.000kg
Product Description
Online consultation to get the lowest price
1. Drive on all rough terrains.
2. Large ground clearance, stronger passability.
3. AC motor drive, smooth driving, low noise.
4. Large capacity batteries, better endurance.
| MODEL | HS1218ERT |
| Max.Working Height | 14m |
| A-Max. Platform Height(In/out) | 12m |
| B-Platform Length | 2.92m |
| C-Platform Width | 1.65m |
| Extension Size | 0.65m(Double Side) |
| D-Heights (Rails Up) | 2.88m |
| Height (Rails Down) | 2.10m |
| E-Length (with Ladder) | 3.75m |
| F-Overall Width | 1.75m |
| G-Wheel Base | 2.3m |
| H-Ground Clearance | 0.2m |
| PERFORMANCE | |
| Platform Capacity | 360kg |
| Extension Capacity | 113kg |
| Max. Occupancy(in/out) | 3/2 |
| Max.Drive Speed (Stowed) | 4.8km/h |
| Drive Speed (Raised) | 0.6km/h |
| Turning Radius (In.) | 2.29m |
| Turning Radius (Out.) | 4.88m |
| Up/Down Time | 54s/50s |
| Gradeability | 0.45 |
| Max. Slope | 2°/3° |
| Control | Proportional Control |
| Drive | Four-Wheel |
| Multi Disc Brake | Four-Wheel |
| Tires (mm) | 26X12-16 |
| Max.Wind Speed | 12.5m/s |
| POWER | |
| Batteries (V/Ah) | 8X6V/370Ah |
| Charger | 100-240VAC/13.5A |
| WEIGHT | |
| Weight | 5730kg |
